ITPOD Vault- servers powering SDS, backup, and analytics
Vault
Areas of Application
Software-Defined Storage (SDS) platforms
Big Data and analytics environments
Corporate email and collaboration servers
Backup, archiving, and disaster recovery solutions
Security, video surveillance, and monitoring systems
Intel Xeon CPU
| Server model | ITPOD-SL401-D36RE |
| Form factor | 4U |
| Processor | 2 x Intel Xeon Scalable 1st and 2nd generations
(TDP up to 205 W) |
| RAM | 24 DDR4 RDIMM/LRDIMM 2666/2933MHz memory slots |
| Storage subsystem | 36 front-facing, hot-swappable universal 2.5″ and 3.5″ SATA/SAS drive slots
2 M.2 NVMe slots (2280 only) |
| Ethernet interfaces | 2 x 1GbE RJ45 (Marvell 88E1512, built-in) |
| Expansion slots | 1 OCP 3.0 slot (PCIe 3.0 x8)
Riser 1: full height PCIe 3.0 slots (3 x8 or 1 x16 and 1 x8) Riser 2: full height PCIe 3.0 slots (3 – x8 or 1 – x16 and 1 – x8) Riser 3: half height PCIe 3.0 slots (2 – x8 or 1 – x16) or 2.5″ Rear Module(2 SATA/NVMe U.2 drives) Riser 4: half height PCIe 3.0 slots (2 – x8 or 1 – x16) or 2.5″ Rear Module (2 SATA/NVMe U.2 drives). 2.5″ Rear Module (2 SATA/NVMe U.2 drives) |
| Server model | ITPOD-SL401-D24RE |
| Form factor | 4U |
| Processor | 2 x Intel Xeon Scalable 1st and 2nd generation (TDP up to 205W) |
| RAM | 24 DDR4 RDIMM/LRDIMM 2666/2933MHz memory slots |
| Storage subsystem | 24 front-facing, hot-swappable universal 2.5″ and 3.5″ SATA/SAS drive slots
2 M.2 NVMe slots (2280 only) |
| Ethernet interfaces | 2 x 1GbE RJ45 (Marvell 88E1512, built-in) |
| Expansion slots | 1 OCP 3.0 slot (PCIe 3.0 x8)
Riser 1: full height PCIe 3.0 slots (3 x8 or 1 x16 and 1 x8) Riser 2: full height PCIe 3.0 slots (3 – x8 or 1 – x16 and 1 – x8) Riser 3: half height PCIe 3.0 slots (2 – x8 or 1 – x16) or 2.5″ Rear Module(2 SATA/NVMe U.2 drives) Riser 4: half height PCIe 3.0 slots (2 – x8 or 1 – x16) or 2.5″ Rear Module (2 SATA/NVMe U.2 drives) |
| Server model | ITPOD-SL401-D24RE-G3 |
| Form factor | 4U |
| Processor | 2 x Intel Xeon Scalable 3rd Gen.
(TDP up to 270W) |
| RAM | 32 slots of DDR4 RDIMM/LRDIMM 3200MHz memory |
| Storage subsystem | 24 front-facing, hot-swappable universal slots for 2.5″ and 3.5″ SATA/SAS drives
2 M.2 NVMe slots (2280 only) |
| Ethernet interfaces | 2 x 1GbE RJ45 (Intel i350-AM2, built-in)
Scalable Gen 3
|
| Expansion slots | 1 OCP 3.0 slot (PCIe 4.0 x8)
Riser 1: full height PCIe 4.0 slots (x16 and 2 x8 or 2 x16) Riser 2: full height PCIe 4.0 slots (x16 and 2 – x8 or 2 – x16) Riser 3: half height PCIe 4.0 slots (2 x8 or 1 x16) or 2.5″ Rear Module (2 SATA/NVMe U.2 drives) Riser 4: half height PCIe 4.0 slots (2 – x8) or 2.5″ Rear Module (2 SATA/NVMe U.2 drives) |
| Server model | ITPOD-SL401-D24RE |
| Form factor | 4U |
| Processor | 2 x Intel Xeon Scalable 1st and 2nd generation (TDP up to 205W) |
| RAM | 24 DDR4 RDIMM/LRDIMM 2666/2933MHz memory slots |
| Storage subsystem | 24 front-facing, hot-swappable universal 2.5″ and 3.5″ SATA/SAS drive slots
2 M.2 NVMe slots (2280 only) |
| Ethernet interfaces | 2 x 1GbE RJ45 (Marvell 88E1512, built-in) |
| Expansion slots | 1 OCP 3.0 slot (PCIe 3.0 x8)
Riser 1: full height PCIe 3.0 slots (3 x8 or 1 x16 and 1 x8) Riser 2: full height PCIe 3.0 slots (3 – x8 or 1 – x16 and 1 – x8) Riser 3: half height PCIe 3.0 slots (2 – x8 or 1 – x16) or 2.5″ Rear Module(2 SATA/NVMe U.2 drives) Riser 4: half height PCIe 3.0 slots (2 – x8 or 1 – x16) or 2.5″ Rear Module (2 SATA/NVMe U.2 drives) |
| Server model |
ITPOD-SL401-D36RE-G4 |
| Form factor | 4U |
| Processor | 2 x Intel Xeon Scalable 4th/5th Gen.
(TDP up to 350W) |
| RAM | 32 slots of DDR5 RDIMM 4400/4800/5600MHz memory |
| Storage Subsystem | 24 front-facing 2.5″ and 3.5″ SATA/SAS hot-swappable universal slots
12 hot-swappable 3.5″ SATA/SAS slots on the rear side 2 M.2 SATA slots (22110/2280) |
| Expansion Slots | 2 OCP 3.0 slots (PCIe x8)
Riser 1: full-height PCIe 5.0 slots (x16 and 2 – x8 or 2 – x16) Riser 2: full-height PCIe 5.0 slots (x16 and 2 – x8 or 2 – x16) Riser 3: half-height PCIe 5.0 slots (1 x16 or 2 x8) or 2.5″ Rear Module (2 SATA/NVMe U.2 drives) Riser 4: half-height PCIe 5.0 slots (1 x16 or 2 x8) or 2.5″ Rear Module (2 SATA/NVMe U.2 drives) |
| Cooling | 8 standard 80mm x 38mm or 80mm x 56mm hot-swappable fans |
| Power Supplies | 2 pcs (800W/1300W/1600W/2200W/2600W)
1+1 redundancy schemes |
AMD EPYC
| Server model | ITPOD-SR401-D36RE |
| Form factor | 4U |
| Processor | 2 x AMD EPYC 7003 (Milan) |
| RAM | 32 slots of DDR4 RDIMM/LRDIMM 3200MHz memory |
| Storage subsystem | 36 front-facing, hot-swappable universal slots for 2.5″ and 3.5″ SATA/SAS drives
2 M.2 NVMe slots (2280 only) |
| Ethernet interfaces | 2 x 1GbE RJ45 (Intel i350-AM2, built-in) |
| Expansion slots | 1 OCP 3.0 slot (PCIe 4.0 x8)
Riser 1: full height PCIe 4.0 slots (x16 and 2 x8 or 2 x16) Riser 2: full height PCIe 4.0 slots (x16 and 2 – x8 or 2 – x16) Riser 3: half height PCIe 4.0 slots (2 x8 or 1 x16) or 2.5″ Rear Module (2 SATA/NVMe U.2 drives) Riser 4: half height PCIe 4.0 slots (2 – x8 or 1 – x16) or 2.5″ Rear Module (2 SATA/NVMe U.2 drives) |
| Server model | ITPOD-SR401-D24RE |
| Form factor | 4U |
| Processor | 2 x AMD EPYC 7003 (Milan) |
| RAM | 32 slots of DDR4 RDIMM/LRDIMM 3200MHz memory |
| Storage subsystem | 24 front-facing, hot-swappable universal slots for 2.5″ and 3.5″ SATA/SAS drives
2 M.2 NVMe slots (2280 only) |
| Ethernet interfaces | 2 x 1GbE RJ45 (Intel i350-AM2, built-in) |
| Expansion slots | 1 OCP 3.0 slot (PCIe 4.0 x8)
Riser 1: full height PCIe 4.0 slots (x16 and 2 x8 or 2 x16) Riser 2: full height PCIe 4.0 slots (x16 and 2 – x8 or 2 – x16) Riser 3: half height PCIe 4.0 slots (2 x8 or 1 x16) or 2.5″ Rear Module (2 SATA/NVMe U.2 drives) Riser 4: half height PCIe 4.0 slots (2 – x8 or 1 – x16) or 2.5″ Rear Module (2 SATA/NVMe U.2 drives) |
| Server model | ITPOD-SR401-D24RE-G2 |
| Form factor | 4U |
| Processor | 2 x AMD EPYC 9004 (Genoa) |
| RAM | 24 slots of DDR5 RDIMM/LRDIMM 4800MHz memory |
| Storage subsystem | 24 front-facing, hot-swappable universal slots for 2.5″ and 3.5″ SATA/SAS drives
2 M.2 NVMe slots (2280 only) |
| Ethernet interfaces | 2 x 1GbE RJ45 (Intel i350-AM2, built-in) |
| Expansion slots | 1 OCP 3.0 slot (PCIe 4.0 x8)
Riser 1: full height PCIe 5.0 slots (2 – x16) Riser 1: full height PCIe 5.0 slots (2 – x16) Riser 3: half height PCIe 5.0 slots (2 – x8) or 2.5″ Rear Module (2 SATA/NVMe U.2 drives) Riser 4: half height PCIe 4.0 slots (2 – x8 or 1 – x16) or 2.5″ Rear Module (2 SATA/NVMe U.2 drives) |
| Server model | ITPOD-SR401-36RE-G2 |
| Form factor | 4U |
| Processor | 2 x AMD EPYC 9004 (Genoa) |
| RAM | 24 DDR5 RDIMM/LRDIMM 4800MHz memory slots |
| Storage subsystem | 36 front-facing, hot-swappable universal slots for 2.5″ and 3.5″ SATA/SAS drives
2 M.2 NVMe slots (2280 only) |
| Ethernet interfaces | 2 x 1GbE RJ45 (Intel i350-AM2, built-in) |
| Expansion slots | 1 OCP 3.0 slot (PCIe 4.0 x8)
Riser 1: full height PCIe 5.0 slots (2 – x16) Riser 1: full height PCIe 5.0 slots (2 – x16) Riser 3: half height PCIe 5.0 slots (2 – x8) or 2.5″ Rear Module (2 SATA/NVMe U.2 drives) Riser 4: half height PCIe 4.0 slots (2 – x8 or 1 – x16) or 2.5″ Rear Module (2 SATA/NVMe U.2 drives) |
